Exhaust With High Flow PSP Downpipes


Thanks, seems to sound better than my cold start with the dual in dual out Magnaflow on the MRT Trail Rated:

View attachment 35078

Borla has a Pro XS with an offset/offset and a center/offset. I assume you used the center/offset (Part No. 400482)?
Yes. Part #400482. Bought em on Amazon.

  • Like
Reactions: rpr
X pipe will cut out lower frequencies and alloy the raspy higher frequencies. H pipe will cancel high raspy frequencies and allow lower frequencies deeper tone and better low end torque.

I can't believe I haven't seen any of these for sale on the FB groups or marketplace here.

Also can't believe that the downpipes change the exhaust tone/frequency so much. I bet the higher flowing cats contribute a lot to that.

X pipe will cut out lower frequencies and alloy the raspy higher frequencies. H pipe will cancel high raspy frequencies and allow lower frequencies deeper tone and better low end torque.
Unfortunately that was my experience with an x-pipe muffler on this truck. Higher frequency tone, very whiny, not good.

This is probably why the MBRP with the double H pipe is one of the better sounding deeper tone exhausts, despite the drone that most complain about.

not so simple. the size and placement of the h-pipe make a dramatic difference in acoustic coupling and sound. adding a second hpipe can attenuate lower frequencies, again depending on size, spacing and location. The same thing with an xpipe, where you place it matters based on the frequency wave length at a given temperature. It can have a larger impact on frequencies if centered at the 1/4 wave length of said frequencies.

That being said you can use h-pipes to tune the sound more effectively than an xpipe as you can couple them with spacing.

The oem h-pipe is that diameter and at that location for frequency attenuation and has no positive impact on low end torque. You can make the argument it negatively impacts low end torque as you are introducing a turbulent piece into the pipe. Turbulence aka pressure drop aka back pressure is the enemy of a turbine wheel and spool.

blending the exhaust pulses is more beneficial from a performance aspect on a N/A engine as those pules are much more defined. On a turbo car the turbo manifold and turbine wheel substantially smooth those pulses so they are not as sharp or abrupt. So again on a turbo car an H-pipe has more effect on the acoustic waveform than functioning like a tuned header directly to cylinder pressure waves of the N/A counterpart.

Thanks for coming to my TED talk....
Understood I was trying to give a short readers digest version of an explanation

On a side note, I get insomnia for two or three hours during the middle of the night and sometimes to get back to sleep. I will start researching something. I’ve been doing quite a bit of reading on exhaust component along with how important the placement is for the components H, X, D, Z pipes, resonators mufflers, and so on. I never knew how complicated it was before but stuff like that interest me. To be honest, it’s reading all of your post over the last several months that have inspired me on that particular subject to learn more about it.

X pipe will cut out lower frequencies and alloy the raspy higher frequencies. H pipe will cancel high raspy frequencies and allow lower frequencies deeper tone and better low end torque.
Muffled xpipe on mine made rasp non existent and deepened the tone significantly. 🤷🏻‍♂️

Our twin turbo motors are like two 3 cyl motors tied together. Two separate but integrated 3 cylinder manifolds two turbos each with their own exhaust. It is highly unlikely both turbos will be balanced. this is where the H pipe comes in to balance the back pressure. With out it acoustically it’s like listening to a cat fight. Placement ideally needs to be at the point where the exhaust gasses stop accelerating due to thermal expansion and just start slowing. On our trucks this where the two exhaust split their path. One side is running across the trans pan and the other side is next to the transmission. Obviously they can’t put it there. So they placed it just after where the exhaust pipes come back together and are running parallel again. (Hopefully now the cats stop fighting and start purring together.)
Pinnaclebuilt does this sound about right?

I ended up swapping my factory H pipe for the X pipe yesterday. I would record a video for the sound bite, but it sounds similar. If not, barely different. I would say there’s a touch more raspiness in the middle of the RPM band, but not by much. The cold starts are a bit tamer and the drone went from a three out of 10 to maybe a 2 1/2 out of 10 not much difference. I will say that the power band does feel much smoother across the board and feels stronger on the high end. So if anyone’s curious, I have the stock exhaust behind the down Pipes with a X instead of a H, valves removed, and four stainless browse resonators added to the system.


Attachments

  • IMG_2741.webp
    189.2 KB · Views: 33
I ended up swapping my factory H pipe for the X pipe yesterday. I would record a video for the sound bite, but it sounds similar. If not, barely different. I would say there’s a touch more raspiness in the middle of the RPM band, but not by much. The cold starts are a bit tamer and the drone went from a three out of 10 to maybe a 2 1/2 out of 10 not much difference. I will say that the power band does feel much smoother across the board and feels stronger on the high end. So if anyone’s curious, I have the stock exhaust behind the down Pipes with a X instead of a H, valves removed, and four stainless browse resonators added to the system.
I could be wrong, but that looks more like a D pipe. A variant of the X pipe. I was wondering how that would work. Now we know.

I got my rasp and drone down significantly w this set up. Don’t judge my welds. PSP- stock front exhaust up to H pipe- 2 16” Amazon cheepo resonators- another H pipe i rigged up - then 2 knock off ultra quiet’s at the ass end. I’ll upload the cold start in a bit. Slight rasp when i get on her hard but cruising is solid. I would’ve loved to keep the nasty growl but every day driving was embarrassing w the rasp.


Attachments

  • IMG_0478.webp
    127.3 KB · Views: 38
  • IMG_0479.webp
    170.1 KB · Views: 39
  • IMG_0486.webp
    227.6 KB · Views: 42
  • IMG_0487.webp
    222 KB · Views: 38
I got my rasp and drone down significantly w this set up. Don’t judge my welds. PSP- stock front exhaust up to H pipe- 2 16” Amazon cheepo resonators- another H pipe i rigged up - then 2 knock off ultra quiet’s at the ass end. I’ll upload the cold start in a bit. Slight rasp when i get on her hard but cruising is solid. I would’ve loved to keep the nasty growl but every day driving was embarrassing w the rasp.
Nice excited to hear
